頻率

50GHz

頻率選件

3.6、8.4、13.6、26.5、43、44、50 GHz，使用混頻器可達 1.1 THz

最大分析帶寬

510 MHz

帶寬選件

25 standard, 40, 85, 125, 160, 255, 510 MHz

最大實時帶寬

510 MHz

實時帶寬選件

85, 160, 255, 510 MHz

1 GHz 時的 DANL

-174 dBm

1 GHz 時，10 kHz 頻偏處的相位噪聲

-136 dBc/Hz

1 GHz 時，30 kHz 頻偏處的相位噪聲

-136 dBc/Hz

1 GHz 時，1 MHz 頻偏處的相位噪聲

-146 dBc/Hz

總體幅度精度

±0.19 dB

三階截獲（TOI），1 GHz 時

+22 dBm

1 GHz 時的最大三階動態范圍

118 dB

應用——通用

89600 VSA 軟件

模擬解調

噪聲系數

相位噪聲

脈沖

實時頻譜分析

MATLAB

應用——蜂窩

GSM/EDGE

LTE/LTE-Advanced

NB-IoT

W-CDMA/HSPA/HSPA+

應用——無線連通性

Bluetooth® (BR/EDR/LE4.2/5.0)

Short Range Communications (ZigBee, Z-Wave)

WLAN 802.11(a/b/g/j/p/n/ac/af/ah/ax)

應用——數字視頻

無

性能水平

◆◆◆◆◆◇

標準衰減器衰減范圍

70 dB

標準衰減器步進

2 dB

100% 截獲概率的最短信號持續時間

3.57 μs

信掩比 > 60 dB 時的可檢測信號持續時間

3.33 ns

無雜散動態范圍

75 dBc

多域帶寬

255 MHz

顯示視圖

密度

頻譜圖

密度頻譜圖

PvT（功率隨時間的變化）頻譜

PvT（功率隨時間的變化）

觸發

FMT（頻率模板觸發）

TQT（時間限定觸發）

電平

射頻猝發

線路

外置

周期

Density

Density Spectrogram

PvT (Power vs Time)

PvT (Power vs Time) Spectrogram

Spectrogram

使用頻率模板觸發的應用軟件

89600 VSA 軟件

實時頻譜分析儀

Pulse Measurement Application

2 GHz 時的 DANL，不配備前置放大器

-155 dBm/Hz

10 GHz 時的 DANL，不配備前置放大器

-157 dBm/Hz

可用應用

 是

臺式

 是

Real-Time Data Streaming

 是

Frequency options

N9030B-503

Frequency Range, 3 Hz to 3.6 GHz

N9030B-508

Frequency Range, 3 Hz to 8.4 GHz

N9030B-513

Frequency Range, 3 Hz to 13.6 GHz

N9030B-526

Frequency Range, 3 Hz to 26.5 GHz

N9030B-544

Frequency Range, 3 Hz to 44 GHz

N9030B-550

Frequency Range, 3 Hz to 50 GHz

Preamplifier options

N9030B-P03

Preamplifier, 3.6 GHz

N9030B-P08

Preamplifier, 8.4 GHz

N9030B-P13

Preamplifier, 13.6 GHz

N9030B-P26

Preamplifier, 26.5 GHz

N9030B-P44

Preamplifier, 44 GHz

N9030B-P50

Preamplifier, 50 GHz

Bandwidth options

N9030B-B2X

分析帶寬，255 MHz

N9030B-B40

Analysis Bandwidth, 40 MHz

N9030B-B1X

Analysis Bandwidth, 160 MHz

N9030B-B85

Analysis Bandwidth, 85 MHz

N9030B-B5X

分析帶寬，510 MHz

Performance Options

N9030B-EA3

Electronic Attenuator, 3.6 GHz, Upgrade

N9030B-EDP

Enhanced Display Package License

N9030B-EMC

Basic EMC Functionality License

N9030B-FP2

Fast Power, up to 40 MHz Bandwidth

N9030B-FT1

Frequency Mask Trigger, Basic Detection License

N9030B-FT2

Frequency Mask Trigger, Optimum Detection License

N9030B-LNP

Low Noise Path

N9030B-MPB

Microwave Preselector Bypass

N9030B-RTS

Real-Time Wideband I/Q Data Streaming

N9030B-TDS

Time Domain Scan

N9030B-EP0

增強的相位噪聲 DDS LO

N9030B-DUA

Duplex IF RTSA

N9030B-RBE

Resolution Bandwidth Extended

Baseband Inputs

N9030B-BBA

I/Q Baseband Inputs, Analog

Calibration Options

N9030B-A6J

ANSI Z540-1-1994 Calibration

N9030B-AMG

Calibration + Uncertainties + Guardbanding (Accredited)

N9030B-UK6

Commercial Calibration Certificate with Test Data

Connector Options

N9030B-ALV

Auxiliary Log Video Output

N9030B-C35

APC 3.5 mm Connector

N9030B-CR3

Connector, Wideband IF Output Upgrade

N9030B-CRP

Connector Rear, Programmable IF Output

N9030B-YAV

Y-Axis Video Output

External Mixing

N9030B-EXM

External Mixing

Real time signal analysis

N9030B-RT1

Real-time analysis up to maximum available BW, basic detection license

N9030B-RT2

Real-time analysis up to maximum available BW, optimum detection, license

Security - PC Features

N9030B-SF1

Security Features, Exclude Launching Programs

N9030B-SF2

Security Features, Prohibit Saving Results

N9030B-SSD

Additional Removable Solid State Drive

Source Connectivity

N9030B-ESC

External Source Control

Application Software

89601B

- 89600 VSA 軟件

N6171A

MATLAB 軟件

N9063C

模擬解調測量應用軟件，多點觸控用戶界面

N9068C

Phase Noise Measurement Application, Multi-touch UI

N9069C

噪聲系數測量應用軟件，多點觸控用戶界面

N9071C

GSM / EDGE / Evo Measurement Application, Multi-Touch UI

N9073C

W-CDMA/HSPA/HSPA+ Measurement Application, Multi-touch UI

N9077C

WLAN 802.11a/b/g/j/p/n/ac/af/ah/ax Measurement Application, Multi-Touch UI

N9080C

LTE/LTE-Advanced FDD 測量應用軟件，多點觸控用戶界面

N9082C

LTE / LTE-Advanced TDD Measurement Application, Multi-touch UI

N9081C

Bluetooth Measurement Application, Multi-Touch UI

N9084C

Short Range Communications Measurement Application, Multi-Touch UI

N9067C

脈沖測量應用軟件，多點觸控用戶界面

N6141C

EMI Measurement Application, Multi-Touch UI

N9054C

VMA 矢量調制分析應用軟件，多點觸控用戶界面

N9061C

Remote Language Compatibility Application, Multi-Touch UI

N9062C

SCPI Language Compatibility Application, Multi-touch UI

E8900-D10

USB read-only licensing dongle - FLEX10

Real Time Recorder

N9030B-RTR

Real-Time Spectrum Recorder and Analyzer Application Example, License
